At WEIDAT, you will find that both our Low/High Carbon Steel Wire and Galvanised Steel Wire meet the timeless British Standard.
Introducing INNOGAL™, a coated steel wire double-dipped and coated with a layer of zinc aluminum, boasting maximum protection even in the most corrosive of environments. This proud WEIDAT innovation is yet another testament to our many years of excellence.
Advantages
- Cost effective
- Superior corrosion resistance performance
- Smooth surface and bright
- Manufactured in accordance to BS EN 10244-2:2012
Innovated for a Superior Standard
649x365.jpg?crc=76334369)
649x365.jpg?crc=4048235022)
-crop-u57778.jpg?crc=36003336)
-crop-u57786.jpg?crc=64399736)
Specification
Standard Gal
NOMINAL DIAMETER
(mm)
≤ 1.60
≥ 8.00
TOLERANCE
(mm)
±0.030
±0.060
COATING MASS
≤ 30
≥ 80
TENSILE
(N/mm²)
380-550
380-550
MID Coated
NOMINAL DIAMETER
(mm)
≤ 1.60
≥ 8.00
TOLERANCE
(mm)
±0.030
±0.060
COATING MASS
≤ 100
≥ 150
TENSILE
(N/mm²)
380-550
380-550
INNOGAL
/ Heavy Gal
NOMINAL DIAMETER
(mm)
≤ 1.60
≥ 8.00
TOLERANCE
(mm)
±0.030
±0.060
COATING MASS
≤ 195
≥ 300
TENSILE
(N/mm²)
380-550
380-550
JIS G3532
NOMINAL DIAMETER
(mm)
≤ 1.60
≥ 8.00
TOLERANCE
(mm)
±0.030
±0.060
TENSILE (N/mm²)
SWM-B
SWM-N
590 - 1270
740 - 1270
320 - 880
500 - 880
JIS G3521
NOMINAL DIAMETER
(mm)
≤ 1.60
≥ 8.00
TOLERANCE
(mm)
±0.030
±0.060
TENSILE (N/mm²)
SW-A
SW-B
SW-C
1420 - 1670
1670 - 1910
1910 - 2160
980 - 1180
1180 - 1370
1370 - 1570
HIGH CARBON BS 4637
Hard Drawn Plain Wire (High Tensile)
BS 4637
NOMINAL DIAMETER
(mm)
≤ 1.20
≥ 8.00
TOLERANCE
(mm)
±0.020
±0.050
TENSILE (N/mm²)
N/mm²
Kgf/mm²
1400 - 2200
143 - 225
1600 - 2000
163 -204
NOMINAL
DIAMETER
Diameter
Tolerance
Yield Strength (Mpa)
Ratio
AGT(%)
Bending
≤12mm
250
5.00
1.15
2d
6 %
≤8mm
4.5%
≥8mm
Rib Spacing
SPRA
Rib Height
Rib Inclination
Min
0.03d
Max
0.15d
Min
0.04d
Max
0.12d
Min
35°
Max
75°
≤6mm
≤12mm
0.035
0.04
NOMINAL
DIAMETER
Diameter
Tolerance
Yield Strength (Mpa)
Ratio
AGT(%)
Bending
4.75mm-10.65mm
500 - 750
1.50
± 4.50%
1.03
3d
